The CX-12 PLUS door interface relay is designed for easy interconnection of automatic doors with access control, time control, telephone entry and fire alarm systems. It provides bi-directional sequencing of two door operators in vestibule applications, and the new PLUS feature supports basic restroom control (locked and unlocked). The relay has eight programming modes with three adjustable time delays, each up to 30 sec. There are two dry, two wet inputs, and two SPDT Form C outputs. Compact in design, it fits anywhere and offers momentary, maintained and latching (ratchet or alternative action) relay operation. This relay combines the features of Camden’s CX-12 switch network, including easy system interconnection, and its CX-22 dual function relay, providing bi-directional door sequencing and basic restroom control and replaces the CX-12 and CX-22 models.
